BAF

Chemical Free Birm Iron Filter

Incoming water passes through a compressed pocket of air contained in the tank. The oxygen precipitates the iron into solid form and is removed when it passes through the filters media bed. Birm acts as a catalyst in the reaction between iron and oxygen that also causes the iron to precipitate into a solid.

As more water passes through the unit the air becomes depleted and the birm becomes overloaded with the iron. Periodic automatic regeneration replenishes the supply of air and cleans the media of filtered iron. Birm is not consumed in the iron removal process and therefore is much more economical than many other iron removal processes.

Certifications

  • System Certification: NSF/ANSI 42-2017

  • Fibreglass Pressure Tank and Control Valve Certifications: NSF/ANSI 44 certified for materials and structural integrity

  • Resin Certification: IAPMO R & T against NSF/ANSI 61 for material safety only

Features

  • Natural oxidation removes iron without chemicals, air pumps or a venturi

  • Low maintenance two tank system

  • Regenerate less frequently than traditional iron filters using up to 50% less water than single tank iron filters

  • Lifetime Warranty on NSF Certified tank; 7 years on NSF Certified control valve

  • Meter Immediate, Meter Delayed, Meter with Day Override, Vacation and Calendar Clock mode

  • Adjustable cycle times

  • Audible Cycle Advance Alarm sounds if the valve is stuck in any position for more than 2 minutes

  • Use less power than an alarm clock (approx. $1.19 annually)

  • Unique bypass with an integrated space saving turbine meter.

  • One-piece design avoids meter jamming

  • Time saving quick connect fittings on bypass and brine line. Power cord even has quick connect for easy valve spin on.

  • Drain line o-ring eliminates need for Teflon

Each filter is available with your choice of the 89 or 765 valve



Resources


Spec Sheet#80160016

Spec Sheet #80160016

BIF BAF 89 Manual
#80155333
